Product Summary:
 Up to Print Speed 50ppm
Up to Res 1200 x 1200 dpi
250 Sheets Input Tray
5.0" Colour LCD Display
70 Sheets ADF Capacity
USB, Network & Wireless
1 Year Return to Base Warranty
Product Description:
Functions Print, Scan, Copy, Fax
Printer Type Laser Printer
Product Dimensions (Width X Depth X Height) 495 mm × 473 mm × 486 mm
Weight 15.9 kg
Print Speed Up to 50 (A4) / Up to 52 (Letter) ppm
Paper Type Plain Paper, Letterhead, Coloured Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper, Bond, Label, Envelope, Env.Thin, Env.Thick
Paper Size A4, Letter, B5 (JIS), A5, A5 (Long Edge), A6, Executive, Legal, Mexico Legal, India Legal, Folio, 16K (195x270 mm), A4 Short (270mm Paper), COM-10, DL, C5, Monarch
Maximum Paper Capacity Up to 1,390 sheets of 80 gsm plain paper (with Added Optional Trays)
Print
Resolution Up to 1200 x 1200 dpi
2-Sided (Duplex) - Printing Paper Type Plain Paper, Letterhead, Coloured Paper, Thin Paper, Recycled Paper
2-Sided (Duplex) - Paper Size A4, Letter, Legal, Mexico Legal, India Legal, Folio (Paper sizes other than A4 are supported only in some countries.)
Paper handling
Tray #1 - Maximum Paper Capacity
Up to 250 sheets of 80 gsm plain paper
Tray #2 - Maximum Paper Capacity
LT-5505: Up to 250 sheets of 80 gsm plain paper
LT-6505: Up to 520 sheets of 80 gsm plain paper
Multi-purpose Tray - Maximum Paper Capacity
Up to 100 sheets of 80 gsm plain paper
Automatic Document Feeder (ADF) Maximum Paper Capacity Up to 70 sheets of 80 gsm plain paper
Paper Output Up to 150 sheets of 80 gsm plain paper (face-down delivery to the face-down output paper tray)
1 sheet (face up delivery to the face up output tray)
Copy
Colour / Monochrome
N/A Yes
Enlarge/ Reduce 25% to 400% (in increments of 1%)
Resolution Up to 1200 x 600 dpi
Scan
Resolution - Interpolated Up to 19200 x 19200 dpi (interpolated) (Windows Only)
Resolution - Scanner Glass Up to 1200 x 1200 dpi
Resolution - Automatic Document Feeder (ADF) Up to 600 x 600 dpi
Fax
Compatibility ITU-T Super G3
Modem Speed 33.6 Kbps
Memory Transmission Up to 500 pages (ITU-T Test Chart #1, Standard Resolution, JBIG)
Out of Paper Reception Up to 500 pages (ITU-T Test Chart #1, Standard Resolution, JBIG)
PC Fax - Sending Yes (Mono)
PC Fax - Receiving Yes (Mono)
Connectivity
Connectivity Hi-SpeedUSB2.0, IEEE 802.11a/b/g/n (Infrastructure Mode), IEEE 802.11a/g/n (Wi-Fi Direct), 10Base-T/100Base-TX/1000Base-T
Network
Wireless Network Security
WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA3-SAE (AES)
*Wi-Fi Direct supports WPA2-PSK (AES) only.
Wireless Setup Support Utility - WPS Yes
Display & Memory
Display Type 5.0" Colour Touchscreen LCD
Memory Capacity
512 MB (For Australia)
2GB (For India)
1GB (For other countries)
Operation
Power Source 220 - 240 V AC 50/60 Hz
Power Consumption - Ready Approximately 31 W
Power Consumption - Sleep Approximately 6.0 W
Power Consumption - Power Off Approximately 0.05 W
Noise Level 54.0 dB (A)
Supported Operating Systems
Supported OS
Windows 10
Server 2012 / 2012 R2 / 2016 / 2019
|
