Product Summary:
 Up to 40ppm Colour & Mono
Up to Res 2400 x 600 dpi
520 Sheets Input Tray
17.6cm Colour Touchscreen
Automatic 2-sided Printing
USB & Network Interface
1-Year Return to Base Warranty
Product Description:
Make the right impression when it counts with vibrant, professional outputs, accurate digital documents, and standout technology that’s game-changing for A4 printing.
Make the right impression when it counts
Experience vibrant, professional colour prints, fast print speeds of up to 40ppm and a robust design that makes this multi-function centre the perfect choice for businesses
Game-changing technology
The Copy Interrupt function allows you to Interrupt a print job in progress at any time to print another copy function job
Complete customization
Automate complex workflows at the touch of a button and integrate third-party software for a tailored document management system
Designed to print for longer
The robust design allows you to produce quality outputs consistently with components that have double the service life, including the belt, engine, and drum unit
Impressive scalability
Engineered to fit into your workspace, the MFC-L9630CDN can be transformed from a desktop device to a highly efficient, floor-standing model
Basic Specs
FUNCTIONS Fax,Print, Scan,Copy
PRINTER TYPE Laser Printer
PRODUCT DIMENSIONS (WIDTH X DEPTH X HEIGHT) 503 mm x 541 mm x 586 mm
PRINT SPEED
A4: Up to 40 ppm
Letter: Up to 42 ppm
PAPER TYPE Plain Paper, Letterhead, Colored Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper
PAPER SIZE A4, Letter, B5 (JIS), B5 (ISO), A5, A5 (Long Edge), B6 (JIS), A6, Executive, Legal, Mexico Legal, India Legal, Folio, 16K (195x270 mm), A4 Short (270mm Paper)
MAXIMUM PAPER CAPACITY Up to 520 sheets of 80 gsm plain paper
WARRANTY 1-year Return to Base Warranty
Print
RESOLUTION Up to 600 x 600 dpi, 2,400 dpi class (2400 x 600) quality
2-SIDED - PAPER TYPE Plain Paper, Letterhead, Colored Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper, Bond, Label, Envelope, Env. Thin, Env.Thick, Glossy Paper
2-SIDED - PAPER SIZE A4, A4 Short (270mm Paper), Letter, Legal, Mexico Legal, India Legal, Folio
Print Media
PAPER INPUT - PAPER TRAY #1 - PAPER TYPE A4, Letter, B5 (JIS), B5 (ISO), A5, A5 (Long Edge), B6 (JIS), A6, Executive, Legal, Mexico Legal, India Legal, Folio, 16K (195x270 mm), A4 Short (270mm Paper)
PAPER INPUT - PAPER TRAY #1 - MAXIMUM PAPER CAPACITY Up to 520 sheets of 80 gsm plain paper
PAPER INPUT - PAPER TRAY #2 - PAPER TYPE A4, Letter, B5 (JIS), A5, Executive, Legal, Mexico Legal, India Legal, Folio, 16K (195x270 mm), A4 Short (270mm Paper)
PAPER INPUT - PAPER TRAY #2 - MAXIMUM PAPER CAPACITY
LT-330CL: Up to 250 sheets of 80 gsm plain paper
LT-340CL: Up to 500 sheets of 80 gsm plain paper
PAPER INPUT - MULTI-PURPOSE TRAY - PAPER TYPE
Width: 76.2 to 215.9 mm / Length: 127 to 355.6 mm
Envelope: COM-10, DL, C5, Monarch
PAPER INPUT - MULTI-PURPOSE TRAY - MAXIMUM PAPER CAPACITY
Up to 100 sheets of 80 gsm plain paper
Envelope; 15 envelopes
PAPER OUTPUT
Face Down Output Tray: Up to 250 sheets of 80 gsm Plain Paper
Face Up Output Tray: Up to 1 sheet
Document Sizes
SCANNER MAXIMUM DOCUMENT SIZE 1
Width: Up to 215.9 mm
Length: Up to 355.6 mm
Copy
COLOUR Yes
MONOCHROME Yes
COPY WIDTH
A4 (ADF/FB): 204 mm
LETTER (ADF/FB): 210 mm
MULTIPLE COPIES Up to 999 pages
ENLARGE/REDUCE 25% to 400% (in increments of 1%)
RESOLUTION Print: Up to 600 x 600 dpi
Connectivity
USB 2.0
IEEE 802.11b/g/n (Infrastructure)
IEEE 802.11g/n (Wi-Fi Direct)
Scan
COLOUR SCANNING Yes
MONOCHROME Yes
COLOUR DEPTH - INPUT 30 bit colour processing
COLOUR DEPTH - OUTPUT 24 bit colour processing
GREYSCALE - INPUT 10 bit colour processing
GREYSCALE - OUTPUT 8 bit colour processing
RESOLUTION - INTERPOLATED Up to 19,200 × 19,200 dpi (interpolated) (Windows Only)
RESOLUTION - SCANNER GLASS Up to 600 × 600 dpi
RESOLUTION - ADF Up to 600 × 600 dpi
SCANNING WIDTH - SCANNER GLASS
A4: Up to 204 mm
LETTER: Up to 210 mm
SCANNING WIDTH - ADF
A4: Up to 204 mm
LETTER: Up to 210 mm
Fax
COMPATIBILITY ITU-T Super Group 3
MODEM SPEED 33.6 Kbps
SCANNING WIDTH (SINGLE-SIDED DOCUMENT)
Letter (ADF/FB): Up to 208 mm
A4 (ADF): Up to 208 mm
A4 (FB): Up to 204 mm
GREYSCALE - MONO 8 bit
RESOLUTION (HORIZONTAL) 203 dpi
RESOLUTION (VERTICAL) - STANDARD - MONO 98 dpi
RESOLUTION (VERTICAL) - STANDARD - COLOUR 196 dpi
RESOLUTION (VERTICAL) - FINE - MONO 196 dpi
RESOLUTION (VERTICAL) - SUPERFINE - MONO 392 dpi
ADDRESS BOOK Yes
GROUPS Up to 20 groups
BROADCASTING 350 locations
SPEED DIAL 300 locations
AUTOMATIC REDIAL 3 times at 5-minute intervals
MEMORY TRANSMISSION Up to 500 pages (ITU-T Test Chart, JBIG)
OUT OF PAPER RECEPTION Up to 500 pages (ITU-T Test Chart, JBIG)
PC FAX - COLOR / MONO Yes (Mono)
Display & Memory
DISPLAY 7.0" TFT ColorLCD
MEMORY CAPACITY 2 GB
Weight
WEIGHT 30.1 kg
Operation
POWER SOURCE 220 V to 240 V AC 50/60 Hz
POWER CONSUMPTION - COPYING Approx. 730 W
POWER CONSUMPTION - READY Approx. 85 W
POWER CONSUMPTION - SLEEP Approx. 16.8 W
POWER CONSUMPTION - POWER OFF Approx. 0.04 W
NOISE LEVEL 56.5 dB (A)
TEMPERATURE - OPERATING 10℃ to 32℃
Network
WIRELESS NETWORK SECURITY
WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES)
*Wi-Fi Direct supports WPA2-PSK (AES) only.
WIRELESS SETUP SUPPORT UTILITY - WPS Yes
Supported OS Windows® Server 2008, Server 2008 R2, 7, 8.1, Server 2012, Server 2012 R2, 10, Server 2016, Server 2019
|
