Product Summary:
 Up to 55ppm Colour & Mono
Up to 55ppm Colour & Mono
2 x 520 Sheet Input Trays
270K Pages Monthly Duty Cycle
Automatic Double Sided Printing
USB & Network Interface
One-Year Limited Warranty
Product Description:
The Lexmark CX943de colour printer is designed for security, usability and reliability for large workgroups at speeds of up to 55 pages per minute*. The simplified, intuitive 10.9 cm touchscreen makes handling your print jobs easy. Media handling is flexible; if you print a lot of envelopes, there’s an envelope option; if you need finished output, there are a staple finisher, staple hole-punch finisher, booklet finisher and Lexmark’s first trifold/Z-fold finisher options. This model also includes standard features that align with the rest of the fleet, like the Trusted Platform Module (TPM)**, which provides an extra set of security features.
General Specs
Part no. 32D0014
Print Technology Colour Laser
Function
Color Printing
Trusted Platform Module (TPM)1
Workgroup Size Large Workgroup
Display Lexmark e-Task 10.9 cm colour touch screen with audible feedback
Media Sizes Supported A6, Oficio, 7 3/4 Envelope, JIS-B4, 9 Envelope, B5, JIS-B5, A3, Ledger, A4, Legal, SRA3, A5, Hagaki Card, Letter, B5 Envelope, C4 Envelope, Statement, C5 Envelope, Executive, DL Envelope, Folio, 10 Envelope
Included Paper Handling 100-Sheet Multipurpose Feeder, 400-Sheet Output Bin, 2 x 520-Sheet Tray/Caster
Standard Ports Gigabit Ethernet (10/100/1000), Front USB 2.0 Specification Hi-Speed Certified port (Type A), Rear USB 2.0 Specification Hi-Speed Certified port (Type A), USB 2.0 Specification Hi-Speed Certified (Type B)
Size (mm - H x W x D) 714 x 620 x 743 mm
Weight 82.5 kg
Packaged Size (mm - H x W x D) 972 x 759 x 849 mm
Packaged Weight, kg 102.1 kg
Printing
Print Speed
Up to:
Black: 55 ppm2 (A4)
Colour: 55 ppm2 (A4)
Print Speed Duplex
Up to:
Black: 55 spm2 (A4)
Time to First Page
as fast as:
Black: 4.9 seconds
Colour: 4.9 seconds
Print Resolution
Black: 1200 x 1200 dpi, 2400 IQ (2400 x 600 dpi)
Colour: 1200 x 1200 dpi, 2400 IQ (2400 x 600 dpi)
Duplex 2-sided: Integrated Duplex
Printable Area metric: 4.2 mm of the top, bottom, right and left edges (within)
Paper Handling
Media Types Supported Labels, Card Stock, Plain Paper, Envelopes, Glossy paper, Refer to the Paper & Specialty Media Guide
Finishing Option Yes
Number of Paper Inputs
Standard: 3
Maximum: 6
Paper Input Capacity
Standard: 1140 pages 75 gsm bond
Maximum: 5140 pages 75 gsm bond
1140 pages 75 gsm bond
Paper Output Capacity
Up to:
Standard: 400 pages 75 gsm bond
Maximum: 3600 pages 75 gsm bond
Paper Weight Range Supported
gsm:
52 - 300 gsm (Standard Tray)
52 - 300 gsm (Multipurpose Feeder)
Finishing Functions
Offset stacking, Stapling, Hole punching, Booklet fold and saddle stapling
Optional Paper Handling
Booklet staple hole punch finisher, Inline Stapler, Dual Catch Bin, Envelope Tray, 2 x 520-Sheet Tray/Caster, Caster spacer, Tri-fold/Z-fold booklet finisher, Staple Punch Finisher, 2000-Sheet Tray, 2000-Sheet Tandem Tray/Caster
Recommended Monthly Page Volume 7,000 - 50,000 pages
Maximum Monthly Duty Cycle Up to: 270 000 pages per month4
A3 Yes
Cartridges & Imaging
Laser Cartridge Yields up to:
26,0005-page Colour (CMY) Cartridges
52,0005-page Black Cartridge
Photoconductor Estimated Yield Up to:
Black: 165,000 pages, based on 5 average letter/A4-size pages per print job
CMY: 165,000 pages, based on 5 average letter/A4-size pages per print job
Cartridge(s) Shipping with Product 18,5005-page Black Toner Cartridge5, 11,5005-page Color (CMY) Toner Cartridges5
Replacement Cartridges: Product functions only with replacement cartridges designed for use in a specific geographical region. See www.lexmark.com/regions for more details.
Hardware
Processor Speed Quad Core 1.2 GHz
Memory
Standard: 4096 MB
Maximum: 4096 MB
Hard Disk Intelligent Storage Drive available; Magnetic Hard Disk available
Printer Languages Standard:
PCL 5, PCLm, PCL 6 Emulation, Personal Printer Data Stream (PPDS), PostScript 3 Emulation, PDF 1.7 emulation, Direct Image
Fonts and Symbol Sets 2 PCL 5/6 bitmap fonts, 158 scalable PostScript fonts, For more information, refer to the Technical Reference., 89 scalable PCL 5/6 fonts, 5 PPDS bitmap fonts, 39 scalable PPDS fonts
Touch Screen Display Yes
Connectivity
Direct USB Yes
Ethernet Network Yes
Network Protocol Support IPSEC w/ IPv4, IPSEC w/ IPv6, IPv6, IPv4, ICMP, TCP, IGMP, UDP
Network Printing Methods Pull Printing, Microsoft Web Services WSD, Enhanced IP (Port 9400), IPP 1.0, 1.1, 2.0 (Internet Printing Protocol)
Network Management Protocols DHCP, APIPA (AutoIP), mDNS, BOOTP, WINS, DDNS, DNS, ARP
Network Security SSL Cipher Configuration, SNMPv3, Certificate Management, TCP Restricted Server List, 802.1x Authentication: MD5, MSCHAPv2, LEAP, PEAP, TLS, TTLS, IPSEC Support (IPv4/IPv6), TCP/UDP Port Access Control, Security Port Lockdown
Optional Local Ports Internal RS-232C serial
Optional Network Ports MarkNet N8230 Fiber Ethernet Print Server, Marknet N8372 WiFi Option
Supported Operating Systems
Microsoft Windows Operating Systems Supported
Windows Server 2008 x64 running Terminal Services, Windows 11, Windows Server 2008 x64, Windows Server 2008 running Terminal Services, Windows Server 2022, Windows Server 2008, Windows 8 x64, Windows Server 2012, Windows Server 2003 x64, Windows RT, Windows Server 2003, Windows Server 2012 R2, Windows Server 2003 x64 running Terminal Services, Windows 8.1 x64, Windows Server 2003 running Terminal Services, Windows 10, Windows 8.1, Windows Server 2008 R2 running Terminal Services, Windows 8, Windows 2000 Server running Terminal Services, Windows Server 2008 R2, Windows 7 x64, Windows Server 2016, Windows XP x64, Windows Me, Windows XP, Windows Vista x64, Windows 2000, Windows Server 2019, Windows NT (4.00/4.00 Server), Windows Vista, Windows 98 2nd Edition, Windows 7
Apple Operating Systems Supported Support is provided through AirPrint and AirScan only
Linux Operating Systems Supported openSUSE Linux 15, Debian GNU/Linux 9.5, Debian 9.4, Debian GNU/Linux 9.6, Debian GNU/Linux 8.11, Ubuntu 16.04, 18.04 LTS, openSUSE Linux 42.3, Red Hat Linux 7.5, 7.6, Fedora 27, 28, 29
Citrix MetaFrame Microsoft Windows Server 2008 R2 Standard Edition running Citrix XenApp 6.0, 6.5, Microsoft Windows Server 2003 and 2003 X64 Edition with Citrix XenApp 5.0, Microsoft Windows Server 2008 R2 Enterprise Edition running Citrix XenApp 6.0, 6.5, Microsoft Windows Server 2012 R2 Datacenter Edition running Citrix XenApp 7.5, 6, 7, 8, 9, 11, 12, 13, 14, 15, 16, Microsoft Windows Server 2012 Datacenter Edition running Citrix XenApp 7.5, 6, 7, 8, 9, 11, 12, 13, 14, 15, 16, Microsoft Windows Server 2012 Essentials running Citrix XenApp 6.0, 6.5, Microsoft Windows Server 2012 Foundation running Citrix XenApp 6.0, 6.5, Microsoft Windows Server 2008 R2 Datacenter Edition running Citrix XenApp 7.5, 6, 7, 8, 9, 11, 12, 13, 14, 15, 16, Microsoft Windows Server 2008 and 2008 X64 Edition with Citrix XenApp 5.0, Microsoft Windows Server 2012 Standard running Citrix XenApp 6.0, 6.5
Novell Operating Systems Supported Novell Open Enterprise Server 2 (SP3) on SuSE Linux Enterprise Server 10 SP4 (x86 and x64) 3, Novell Open Enterprise Server 11 (SP3) on SuSE Linux Enterprise Server 11 SP4 (x86 and x64), Novell NetWare 6.5 Open Enterprise Server, Novell Open Enterprise Server 15 (SP1) on SuSE Linux Enterprise Server 11 SP4 (x86 and x64), Novell Open Enterprise Server 11 (SP3) on SuSE Linux Enterprise Server 12 SP1 (x86 and x64)
Electrical & Operation
ENERGY STAR Yes
ENERGY STAR Typical TEC:
Electricity Consumption 0.86 kilowatt-hours per week
Noise Level Operating:
15 dBA (Idle)
50 dBA (Print)
Duplex Print Noise Level Operating:
52 dBA
Average Power
0.1 watts (Hibernate Mode)
1.3 watts (Sleep Mode)
76 watts (Ready Mode)
767 watts (Printing)
Specified Operating Environment
Humidity: 8 to 80% Relative Humidity
Altitude: 0 - 2500 metres
Temperature: 10 to 32°C (50 to 90°F)
Product Certifications
ENERGY STAR, ICES-003 Class A, BSMI Class A, VCCI Class A, FCC Class A, NOM-032, UL, cUL, NOM, US FDA/CDRH, IEC 60825-1, CB Report, ISO-532B, CE (EU) DoC, EFTA (CE), KC logo, CCC, C-tick DoC, EuP, CECP, CEL, EC 1275/2008, ECMA-370, TED, SII, TER, SABS, UL-AR, GS Mark, Green Dot, ISO-9296, COC, CCD-035 EcoLogo, Green Mark, EPEAT, China Green Product (CGP)
In the Box
Up to 11,500*-page cyan, magenta, yellow toner cartridges
Up to 165,000** pages black photoconductor and up to 165,000** pages CMY photoconductor
Up to 18,500*-page black toner cartridge
Stability Information Sheet
Software and Documentation CD
Setup Sheet (Network and Local Attachment)
Safety Information Sheet
Power Cord(s)
Lexmark CS943de colour laser printer
Warranty Sheet/Book (Country dependent)
EMEA Contact Sheet (Country dependent)
Warranties
Product Warranty 1-Year Onsite Repair, Next Business Day
|
Download .pfd brochure for Lexmark CS943de A3 Colour Laser Printer
Image may differ from actual product
|
