Canon iPF PRO-6100S 60" 8 Colour Large Format Inkjet Printer

The 8-color 60-inch imagePROGRAF PRO-6100S printer designed for the poster and signage markets exceeds expectations for speed and color consistency in a large format production printer. The use of a 1.28-inch wide 12-channel integrated compact print head, LUCIA PRO ink set , a high-precision mechanical platform and the L-COA PRO high-speed image processing engine achieves a balance between high-speed printing and exceptional print quality.



The imagePROGRAF PRO-6100S has been designed to include intelligent technology for advanced media handling, increased security features, borderless printing and improved operational design.



Printer Type

8-Color 60-inch Printer

Number of Nozzles

Total: 18,432

All colors: 1,536 nozzles

Nozzle Pitch

600 dpi x 2

Non-firing nozzle detection and compensation

Print Resolution (Up to)

2400×1200dpi (Max)

OS Compatibility

32bit: Windows® (7/8.1/10)

64bit: Windows 7, Windows 8.1, Windows 10Windows Server 2008R2, Windows Server 2012/2012R2Windows Server 2016, Windows Server 2019

Mac (OS 10.11.6), (Mac OS 10.12 – 10.15)

Standard Interfaces

USB 2.0 High-Speed

10/100/1000 Base-T/TX

Wireless LAN (IEEE 802.11 b/g/n)

USB Thumb Drive

Ink Droplet Size

minimum 4 picoliter

Ink Capacity

160, 330, or 700ml per color*

Ink Droplet Size

Pigment based LUCIA PRO Ink

Color Set

Photo Black, Matte Black, Cyan, Magenta, Yellow, Photo Cyan, Photo Magenta, Gray

Hard Drive

500GB

Media Width

Cut Sheet - 6- 60

Roll Feed - 6 - 60

Media Thickness

Roll: 0.07 - 0.8 mm (2.8 - 31.5mil)

Maximum Roll Print Length

Roll Feed - 59' (18 meters)**

Maximum Media Roll Diameter

6.7 (170mm)

Borderless Printing Width

Custom roll width 6 – 60 with micro margin technology

Paper Feed Method

Roll Feed: Two Rolls, Front-loading, Front Output

Manual Feed: Front-loading, Front Output

Languages

Swift Graphic Raster (SGRaster)

Noise Level Approx

Operation: 49 dB (A) or less

Accoustic Power: 6.7 Bels or less

Physical Dimensions

46.0 (H) x 78.7 (W) x 38.7 (D) (with basket open)

Weight

approx.302 lbs (roll holder included, no inks, no print heads)

Power Source

AC 100-240V（50-60Hz）

Power Consumption

Maximum: 109 W or less

Standby 2.0 W or less

Power Off: 0.3 W or less

Operating Environment

Temperature: 59 - 86°F

Relative Humidity: 10-80% (No Condensation)

User-replaceable items

Print Head (PF-10)

Maintenance Cartridge (MC-30)

Ink Tanks (PFI-1100/PFI-1300/PFI-1700)

Software Included

Professional Print & Layout4, imagePROGRAF Printer Driver, Quick Utility Toolbox, Accounting Manager, Device Management Console, Media Configuration Tool, PosterArtist Lite (PC only), Printer Driver Extra Kit (Free Layout and Advanced Preview), Direct Print & Share, Gallery Wrap Feature
