Product Summary:
 Max. Print Speed 170mm/sec.
Up to Print Resolution 203 dpi
40, 58 & 80mm Media Widths
40, 58 & 80mm Media Widths
Automatic Next Level Printing
USB & Ethernet Interface
One Year Onsite Warranty
Product Description:
Cost efficient
As the TM-L90LF prints both liner-free labels and receipts in order to improve the user's operational efficiency and total cost of ownership (TCO). As the printer works with adhesive-backed media, users are able to accurately label food and drink orders - thereby increasing customer satisfaction and user accuracy.
Order processing speed
With print speeds of up to 170mm/sec, the potential benefits to the user are clear: fast order (and checkout) processing, faster drive-through services and improved customer satisfaction.
Built-in taken sensor
The next label prints automatically as the printed one is taken.
Flexible installation
Users can position the printer in the most convenient spot, thanks to a choice of vertical, horizontal or wall-mounted (using optional bracket) installation.
Saves paper
The TM-L90LF features improved paper reduction functionality that includes back feed capability, line feed adjustment and a smaller sized font. It can be set up to cut through adhesive areas, which saves paper. To further reduce paper consumption, the automatic top margin reduction function prints the top of the next receipt before cutting the current one when printing continues after auto cutting. It supports 1.5-inch, 2-inch or 3-inch media widths.
Key Features
Built-in taken sensor Automatic next label printing
Media flexibility 40, 58 and 80mm media widths
Speed Print speeds of up to 170mm/sec
Paper-saving Improved paper reduction function
Easy installation Three mounting positions
Features
Share the printer easily and efficiently with various other systems with the help of built-in Ethernet port
Save your space with the wall-mount option
The printer is capable of printing sharp and detailed monochrome documents quickly
A smart and inexpensive solution to print temporary documents
Enjoy the optimal performance in today's on-demand labelling applications
Technical Specs
Interfaces/Ports
USB Yes
USB Host Yes
Network & Communication
Ethernet Yes
Ethernet Technology Fast Ethernet
Power Description
Input Voltage 24 V DC
Power Source Battery
Media Types & Handling
Media Type Label
Liner-free Label
Maximum Label Width 80 mm
Physical Characteristics
Weight (Approximate) 1.90 kg
Form Factor Wall Mount
Height 203 mm
Width 140 mm
Depth 140 mm
Product Color Dark Grey
Miscellaneous
Package Contents
TM-L90LF (681): UB-E04, built-in USB, PS, EDG, Liner-free
PS-180
User Manual
Country of Origin China
Noise Level 52 dB
Technical Information
Application/Usage Desktop
Recommended Use Label Print
Installation Horizontal/Vertical
Print Color Capability Monochrome
General Information
Product Type Direct Thermal Printer
Manufacturer Part Number C31C412681
Manufacturer Website Address http://www.epson.com.au
Manufacturer Epson Corporation
Product Model TM-L90LF (681)
Product Name TM-L90LF (681): UB-E04, built-in USB, PS, EDG, Liner-free
Product Series TM-L90
Brand Name Epson
|
