Product Summary:
 Up to Print Speed 25 Sec.
Up to Res 2400 x 1200 dpi
1GB Standard Memory
Automatic sheet feeder
1376 Printhead Nozzles
USB, Network & Wireless
One Year Limited Warranty
Product Description:
Featuring a modern office design that compliments its environment and performance to match. Print multi-size jobs easily with auto switching between roll and tray. Enjoy high-speed printing as fast as 25 sec per A1/D plot. 1 GB memory.
Print speed 36-in: 25 sec/page on A1, 82 A1 prints per hour
Print resolution Up to 2400 x 1200 optimized dpi
Technology HP Thermal Inkjet
Margins Roll: 5 x 5 x 5 x 5 mm / Sheet: 5 x 5 x 5 x 5 mm
Ink types Dye-based (C, M, Y); pigment-based (K)
Page Yield 20 ml of ink yields 101 A1/D pages, taking into account maintenance routines
Ink drop 5.5 pl (C, M, Y); 12 pl (K)
Printheads 1 (cyan, magenta, yellow, black)
Printhead nozzles 1376
Line accuracy ±0.1%
Minimum line width 0.02 mm
Max optical density 8 L* min/2.10 D
Handling Sheet feed, roll feed, automatic sheet feeder, media bin, automatic horizontal cutter
Roll size 36-in: 279 to 914 mm
Sheet size Auto sheet feeder: 210 x 279 to 330 x 482 mm / 36-in manual feed: 210 x 279 to 914 x 1897 mm
Standard sheets Auto sheet feeder: A4, A3 / 36-in manual feed: A4, A3, A2, A1, A0
Grammage 60 to 280 g/m² (roll/manual feed); 60 to 220 g/m² (auto sheet feeder)
Thickness Up to 0.3 mm
Applications Line drawings; Presentations; Renderings
Memory 1 GB
Hard disk None
Interfaces Gigabit Ethernet (1000Base-T), Hi-Speed USB 2.0, Wi-Fi 802.11a/b/g/n
Print languages (standard) HP-GL/2, HP-RTL, CALS G4, JPEG, URF
Drivers Raster driver for Windows and macOS
Printer 36-in: 1317 x 555 x 932 mm
Shipping 36-in: 1470 x 575 x 646 mm
Printer Weight 36-in: 41.7 kg
Shipping Weight 36-in: 62 kg
What in the Box HP DesignJet Studio series printer, printer stand, automatic sheet feeder, roll cover, printhead, introductory ink cartridges,spindle, quick reference guide, setup poster, power cord
|
